Audiopipe Micro 2 Channel Marine Powersports Class-D Amplifier, 320 Watts
160 Watts x 2 @ 2 Ohms
100 Watts x 2 @ 4 Ohms
320 Watts x 1 @ 4 Ohms (Bridged)
DIM (W X H X L) 3.5″ x 1.6″ x 7.6″
Fusing: 30 Amp
Class-D
2 Ohm Stable
High Pass Crossover: 40 – 400Hz @ 12dB
Low Pass Crossover: 40 – 400Hz @ 12dB
Water Resistance: IPX67
S/N Ratio:> 90dB
THS: <0.08%
Frequency Range: 20Hz-20kHz
Advanced Full Range Class D Amplifier
Full Range Class D Using IR (International Rectifier) Control Chips
Small Foot Print
Waterproof IP67 Rating
SMD with 4 Layer Fiberglass PCB Design
Protection: Thermal, Over Current & Short
