Marts Digital Monoblock Amplifier, 3000W RMS, 1 Ohm Stable
Fan Cooled – Class D Monoblock Amplifier – 3000 Watt
1 x 3100 Watts RMS @ 1 OHM – 12.6 VDC
1 x 1800 Watts RMS @ 2 OHMS – 12.6 VDC
1 x 970 Watts RMS @ 4 OHMS – 12.6 VDC
Dimensions: (H x W x D) 9” x 2.8” x 8.6”
Recommended Fuse: 150A external fuse (not included)
Class D
1 Ohm Stable
Frequency Response: 10Hz – 20kHz
High Pass Crossover (HPF): 10 – 90Hz
Low Pass Crossover (LPF): 90 – 20 kHz
Bass Boost: 50Hz – 70 Hz (0 to +10dB @ 50 Hz)
RCA Inputs
SIGNAL TO NOISE RATIO: >90dB
EFFICIENCY: 79%
Protection: Short, Over/Under Voltage & Thermal
LED: Clipping, Power, Protect
Fan Cooling
Remote Bass Control
You must use 100% oxygen free copper wire at its maximum size.
Copper clad aluminum wire, CCA, will cause failure.
