An all in one radio replacement and SWC interface, the innovative RadioPRO5 comes pre-loaded with OnStar retention, amplifier retention, SWC software, navigation based output signals and other features that save time and money during installation.
Combines OS-4 & SWI-RC Interface
Product Features
- Retains OnStarĀ® and functions when the factory radio is replaced
- OnStar volume adjustment
- Retains OnStar Turn-By-Turn voice prompts
- Retains steering wheel controls (pre-programmed)
- Retains Factory Bluetooth (2009+ model vehicles)
- Retains rear seat audio controls
- Retains factory satellite radio with text displayed in the Driver Information Center (cluster display)
- Retains all warning chimes (chime module included)
- Retains back-up sensors/park assist and back-up camera signal
- Retains factory Bose and premium Bose audio systems (Y91 digital system does not support fading from aftermarket radio)
- Compatible with non-amplified audio systems
- Dual zone function
- Chime volume adjustment
- Rear seat audio and video (GMRVD) required
- Retained accessory power output (RAP)
- Reverse wire output
- VSS (Vehicle Speed Sense) output
- Illumination output and parking brake output
- Includes antenna adapter
- Updatable using the PAC-UP
> 2012+ GM trucks and SUVs equipped with factory navigation radios require the RP5-GM32
> 2014+ Silverado and Sierra: Only compatible with 2500 & 3500 series trucks with non-navigation radios. 1500 series must use the RP5-GM51. 2500 & 3500 series trucks with navigation radios must use the RP5-GM32
> In Premium Amplified Systems there will be no fading capability of the aftermarket stereo.
> Chevrolet Express vans & GMC Savannah vans equipped with diesel engines are not compatible
> In order to retain the factory XM tuner the aftermarket head unit MUST be equipped with an auxiliary input
> In order to retain the factory XM tuner the vehicle must be equipped with steering wheel controls and a driver information center
> Sony Bluetooth SWC commands are only supported with revision 1.6.6.14 or higher
> Does not retain escalating tones of parking sensor proximity
> Does not retain lane departure or forward collision warning tones
