Pioneer Single DIN Modular 9″ Floating Display Mechless Digital Media Receiver, Apple CarPlay®, Android Auto™, Amazon Alexa via Pioneer Vozsis, Bluetooth®, Wifi®
Features:
Modular Chassis with Floating 9″ WXGA capacitive display
Single DIN Chassis with 9.0″ Floating-screen WSVGA (1024×600) capacitive display
Apple CarPlay® (Wired, Wireless)
Android Auto™ (Wired, Wireless)
Amazon Alexa via Pioneer Vozsis
Built-in Wifi®
HD Radio™
SiriusXM-Ready™ (Tuner Sold Separately)
iDatalink® Maestro™ and Metra Axxess™ compatible
Remote Control Wireless control with PxLink
PRODUCT PERFORMANCE
Continuous Power Output: 22 W x 4-Channel
Max Power: 50 W x 4-ch 4 ohm ,50 W x 2-ch 4 ohm 70 W X 1-ch (subwoofer) 2 Ohm
RMS Power Output (CTA-2006): 14 W RMS x 4-ch 4 ohm
RCA Preout Voltage: 4V
RCA Preamp Outputs: 6 Channel
GENERAL
Fixed
Music Browser: USB
Multi-Language Display: English, French, Spanish Portuguese, Chinese (Simplified)
Steering Wheel Control Ready (Adapter Sold Separately)
Remote Control Wireless control with PxLink
Display:
Back Light: LCD
Brightness Control
Color Customization: 5 display colors, 112 key colors
Device (Non-DIN/Modular Unit): 1-DIN, Floating
Dimmer Control: Automatic with vehicle illumination, Timer Controlled, Manual
Display Off Mode
Home Screen Customization
Monitor Mechanism: Adjustable, Floating
Resolution: 1024 x 600
Screen Size/Aspect Ratio: 9″/16:9
Touch Screen: Capacitive
NAVIGATION
External GPS Antenna
BLUETOOTH
Advanced Audio Distribution Profile (A2DP)
AVRCP: 1.6
Built-in Bluetooth®
Dual Phone Connection
Hands-Free
Microphone Included
Phone Registation: 5-phone
Secure Simple Pairing (SSP)
Serial Port Profile (SPP)
TUNER
Best Station Memory
HD Radio™: Built In, Artist Experience, Multicasting
Hybrid Radio
Local Seek tuning
Presets: 18 FM / 6 AM
RDS Tuner
SiriusXM-Ready™ (Tuner Sold Separately)
INTEGRATION
Amazon Alexa: Paired with Pioneer Vozsis
Android Auto™: Wireless Connection or Wired USB Connection
Apple® CarPlay: Wireless Connection or Wired USB Connection
Mobile Operating System: Android, Apple iOS
Music Playback (MTP)
Pandora®: With Apple CarPlay or Android Auto
Pioneer App Compatibility: PxLink
Siri® Eyes Free (VR) (Internet Required): iPhone Only
Spotify: With Apple CarPlay or Android Auto
Voice Control
Weblink: 3.0
Wifi: Tethering, WiFi Hotspot
DIGITAL MEDIA PLAYBACK
Audio Playback via USB: MP3 Audio Playback, WMA Audio Playback, WAV Audio Playback (Hi-Res), AAC Audio Playback, FLAC Audio Playback (Hi-Res), DSD Audio Playback (Hi-Res)
Audio Video Playback via USB: .avi, .mpg/mpeg, .divx, .mp4, .3gp, .mkv, .flv, .wmv/.asf, .m4v, H.263, H.264, .ts/.m2ts/.mts
Image Display Via USB: BMP, JPEG, PNG
AUDIO
Advanced Sound Retriever: Mode-1/Mode-2/Off
Audio Bass Boost
Auto Sound Levelizer (ASL)
Balance Control
Built-in Amplifier: MOSFET 50 W x 4
Crossover Network Mode: HPF/Band Pass/LPF
Crossover Standard Mode: HPF/LPF
Customizable Graphic Equalizer: 13 Band
DA Converter: Pioneer Dual-Core 48-Bit DSP/DAC
Digital Signal Processor: Built-in Pioneer Dual-Core 48-Bit DSP/DAC
Dynamic Bass Enhancer: Six Levels
Easy EQ (EEQ) Preset Equalizer
Listening Position Selector
Loudness: High/Mid/Low/Off
Speaker Output: 4-ch
Spectrum Analyzer
Subwoofer Control
Time Alignment: manual
EXPANDABILITY
Audio Video Inputs: Input 1 – Backup Camera Dedicated, Input 2 – AUX (Minijack), Input 3 – A/V or 2nd Camera
OEM Integration: iDatalink Maestro RR, iDatalink Maestro RR2, Metra Axxess
OTA Update Compatible
Parking Assist Lines
USB: Single Rear Type-A (5V, 1-1/2 A)
USB Direct Control for iPhone®: 5S and newer
