Max Power Handling: 3,800w
RMS Power Handling: 1,900w
Efficiency (1w/1m) 86.1
Voice Coil Configuration 3” Dual 2Ω
Motor Volume 272oz.
Mounting Depth 8”
Optimum Sealed Enclosure ft3: 2.0
Optimum Ported Enclosure ft3: 4.0
Double Stacked Magnets
Overcompensating Motor Structure for Increased Magnetic Strength
12mm T-Yoke & Top Plate Improve Low Frequency Dynamics
Vented T-Yoke & Frame Reduces Voice Coil Heat Build-up
Non-Magnetic Non-Resonate Die-Cast Aluminum Frame
3″ 4-Layer Voice Coil w/ Direct Connect Wire Increases Power Handling
High-Temperature Tolerance Adhesives Resist Thermal Failure
Non-Transfer Spruce Pulp Cone w/ UV & Chemical Protection
Stitched and Glued Surround/Cone Joints for Strongest Bonding
Extended Excursion Polyether Foam Surround w/ UV Protection
Dual Poly-Cotton Suspension Dampen Violent Accelerations
Stitched Voice Coil Leads Prevent Potential Damage
1-pc Gasket/Trim Ring w/ Concealed Mounting Holes Included
Sold Individually
