Stetsom *1637* 5-Channel Digital Audio Crossover
Stetsom’s STX104 is a crossover designed to provide high performance combined with sound fidelity in 5 channels. It has high reliability with very low noise levels and harmonic distortion, ideal for professional sound.
Subsonic Filter: Flat/30/50/80 Hz
Phase Control
Mono/Stereo
Bass Boost: 0-12dB
Inputs: Front & Low/Rear
Outputs: Flat, Low/Rear, Mid Low, Mid, High
Via High 400Hz – 10KHz (12 dB/8ª)
Via Mid 150Hz – 12.5KHz (12 dB/8ª)
Via Low 70Hz – 10KHz (12 dB/8ª)
Maximum Output Voltage 9V RMS
Maximum Input Voltage 4V RMS
Signal to Noise >90dB
Input Impedance 10K OHMS
Harmonic Distortion < 0.02% THD
Channel Separation > 80dB
Frequency Response 20Hz – 200Khz
Supply Voltage 10V – 16V DC
Current Consumption 0.25A MAX
Impedance Output 50 OHMS
(W x H x D) 10.4″ x 1.3″ x 6.3″
