Stromberg Bike Bunk Trailer Carrying System
A raised receiver on the “A” frame is the perfect place to put your bikes
Allows any RV approved bike rack designed for a 2″ receiver to fit
Your application will be determined by the turning radius and positioning of the rack
All steel design supports up to 100 lbs.
33.5″ from the top of your A-frame to the top of the Bike Bunk cross tube, 29” from the top of your A-frame to the bottom of the receiver tube on the cross tube. Due to the bent design on the vertical posts, lower pockets can be mounted on your A-frame at widths varying from 14″ to 55″. Max A-frame bar height of 6″
(Bike Rack NOT Included)
If you have an Airstream, please note the clearance does not accommodate the 30 gal covered LP tanks.
