Sundown Audio 12″ Shallow Mount Woofer, 600W RMS/1200W MAX, Dual 4 Ohm Voice Coils
1200W MAX
600W RMS
Dual 4 Ohm Voice Coils
The SML series is a revolutionary line of subwoofers offered by Sundown Audio. An inch shallower than our SLD series, it delivers nearly the excursion, making it an ideal choice for customers seeking an extremely shallow driver with deep bass. Designed to fit under or behind your seat, the SML series performs exceptionally well in small enclosures.
Black Aluminum 2.5” voice coil former for superior heat dissipation
High temperature 4-layer copper voice coil wire
Stitched-on “Mini-XL” tinsel Leads to prevent fatigue and failure
Vented pole-piece and vented magnetic gap
Dual-magnet design for smooth acoustic response
Custom tooled cone shape for reduced mechanical noise over high excursion
Bolt-through motor design to ensure maximum longevity and ruggedness
VAS-L: 29.593
Qes: 0.617
Qms: 3.035
Qts: 0.513
BL-NA: 22.801
Mms-Grams: 186.887
Cms-uM/N: 85.771
Sensitivity-dB @ 1w/1m: 86.7
Xmax: 11mm
Displacement (Inches): .05 cu ft
Depth (Inches): 4.45
Motor Diameter (Inches): 6.14
Ported Enclosure Size: 1.25-1.75 cu ft
Recommended Port Area: 26-30 sq in
Recommended Port Tuning: 35hz
Sealed Enclosure Size: 0.75-1.0 cu ft
The boxes say 500W but Sundown has confirmed they now rate these at 600W RMS
(However they have no plans of updating the boxes for the subs.)
Sold Individually
