4 x 500 Watts RMS @ 1 Ohm (14.4VDC)
4 x 300 Watts RMS @ 2 Ohms (14.4VDC)
4 x 200 Watts RMS @ 4 Ohms (14.4VDC)
(W x H x D) 8.25” x 2.75” x 9.75”
1 Ohm Stable
Full Range Digital Class-D Amplifier
MOSFET PWM Power Supply
Low Pass Filter: 50 – 6000 Hz (12dB/Octave)
High Pass Filter: 15 – 6000 Hz (12dB/Octave)
RCA Inputs
S/N Ratio: 100 dB
In put Sensitivity: 5V Max
Working Voltage: 9V – 16V DC
4-Way Protection (Thermal, Hi & Low Voltage, Short )
LED Clipping Indicator
Fuse (180A) and Fuse Holder NOT Included
