1 x 8000 Watts RMS @ 1 Ohm
1 x 4000 Watts RMS @ 2 Ohms
1 x 2000 Watts RMS @ 4 Ohms
1 x 16000 Watts RMS @ 2 Ohms – Linked
(W x H x D) 10.08″ x 2.96″ x 30.71″
1 Ohm Stable
Digital Class-D Linkable Mono Block Amplifier
Dual MOSFET PWM Power Supply
Frequency Response: 10 – 250 Hz
Low Pass Crossover: 35 – 250 Hz (24dB/Octave)
Subsonic Filter: 10 – 50 Hz (24dB/Octave)
Bass Boost: 0 – 9 dB @ 45 Hz
Phase Control
RCA In/Outputs
RCA Link In/Outputs
4-Way Protection (Thermal, Voltage, Short & DC Offset)
Remote Bass Control with LED Voltage/Temperature Display & Clipping Indicator
Fuse and Fuse Holder NOT Included
