Full Range Class-D 2 Channel Amplifier with Bluetooth
2 x 270 Watts RMS @ 2 Ohms
2 x 150 Watts RMS @ 4 Ohms
1 x 540 Watts RMS @ 4 Ohms Bridged
Dim : (W x H X D) 8.1″ x 1.87″ x 4.3″
IP67 – Waterproof
Bluetooth Music Streaming
2 Ohm Stable
Variable Gain: 0.3 – 6 V
Hi/Low Pass Crossover: 50 – 500 Hz
Slope: 12dB/Octave
Frequency Response: 20 – 20,000 Hz
Short, Thermal & Voltage Protection
THD: < 0.3%
S/N Ratio: > 90 dB
Designed Specifically for All Powersports, Marine, Motorcycle Applications
Frequency Controls in a Sealed Compartment
Ulta-Compact for Easy Installation
Surface Mount Component Technology
Power/Protect LED Status Indicator
Low Signal to Noise and FM Noise Rejection
Our SAMv.2 amplifiers are ideal for your boat, bike or UTV. On the trail or on the road, this micro amplifier fits in tight spaces, but don’t let the size fool you – they pack some big power. SAM-series amps are rated IP67, certified to withstand full submersion when getting wild off-road, or when its time to clean up when the fun is done. Both of our multi-channel amps have built-in Bluetooth, so a source unit is not needed! Just sync to your phone and enjoy! Ready to go big? With the included line output, it’s easy to add additional amplifiers to the system.
